Inverter 20KW Hybrid Deye 48v-380v LP3

· Nominal output power (AC): 20 kW

· Compatible battery type: Low voltage (48 V)

· Number of MPPT: 2 independent

· Maximum charge/discharge current: Up to 350 A

· Maximum efficiency: 97%

· Photovoltaic input voltage: 160 V – 800 V

· Parallel connection capacity: Up to 10 units, both in grid-connected and stand-alone mode

· Three-phase output with phase imbalance: Allows up to 100% imbalance, with a maximum of 50% of the nominal power per phase

· Additional functions: Diesel generator support, 6 programmable charge/discharge periods, transformer-isolated design

Low voltage (48V) with high charging capacity:

· It allows working with 48 V batteries, which are safer and easier to integrate.

· Ideal for small-medium residential and commercial systems.

Three-phase with phase imbalance:

· It can supply unbalanced loads, up to 100% on one phase (maximum 50% power per phase).

· Very useful in installations where there is no balanced consumption by phases.

Parallel connection (up to 10 units):

· It can be easily expanded if more kW is needed.

· It works both connected to the network and in isolated mode.

2 independent MPPT:

· Optimizes photovoltaic generation, even with different orientations or shadows.

Smart features:

· Upload/download scheduling in 6 periods.

· Compatible with diesel generator.

· EPS (critical output) for supply in case of outage.

Compatible with many batteries (Deye, Pylontech, Dyness, etc.):

· Flexibility to choose the battery brand you prefer.

Ideal for self-consumption installations with storage:

· For homes, farms, industrial warehouses, or small businesses seeking energy independence.
